Inline Selective Soldering Machine

Inline Selective Soldering Machine

  • max solder temperature 350℃
  • solder pot capacity 15 KG
  • dimension L1280mm X W1400mm X H1650mm
  • Net weight 380KG
  • Product description: Inline Selective Soldering Machine, max solder temperature 350℃ , solder pot capacity 15 KG, dimension L1280mm X W1400mm X H1650mm, Net weight 380KG
  • INQUIRY

Inline Selective Soldering Machine

Products description


Inline Selective Soldering Machine

Advantageous:
(1) Integrated full-functional model, the whole motion platform integrated spray and welding, compact space.
(2) PCB plate fixed, spray and welding platform moving.
(3) High welding quality, greatly improve the pass rate of welding.
(4) Modular design of SMEMA online transportation, support customers for flexible line formation.
(5) Full PC control. All parameters can set in PC and saved to PCB menu, like moving path, solder temperature, flux type, solder type ,n2 temperature etc, best trace-ability and easy to get repeat soldering quality.
Standard machine include:

Serial

Item

content

Quantity

1

Controlling system

PC & monitor

1 set

Live on monitor camera

motion control

2

PCB Motion table

xyz motion table

1 set

3 axis equipped with ball screw & linear guild rail

3 axis equipped with servo motor & driver

3

Fluxing system

Imported fluxing jetting valve

1 set

flux tank

flux pneumatic system

4

preheating system

IR heater at bottom

1 set

5

Soldering pot

15kg capacity solder pot, impeller, tunnel, servor motor

1 set

solder temperature over heat alarm system

solder temperature controlling system

n2 inline heating system

Standard equipped solder nozzle(Inner 4mm x 3pcs, 5mm,6mm )

6

Conveyor system

PCB side clamping system

1 set

7

Machine chassis

machine frame/cover & painting

1 set

Keywords:

Wave Soldering Machine, Dual Rail Wave Soldering Machine, High End Wave Soldering Machine, Nitrogen Wave Soldering Machine, China Wave Soldering Machine, Wave Soldering Machine Manufacturer.

Flason Electronic Co.,ltd provide a full SMT assembly line solutions, including SMT Reflow OvenWave Soldering MachinePick and Place MachineSMT Stencil PrinterSMT AOI SPI MachineSMT Reflow OvenSMT Peripheral EquipmentSMT Assembly lineSMT Spare Parts  etc any kind SMT machines you may need, please contact us for more information: wechat whatsapp:+8613691605420, Skype: flasonsmt, Email: sales@flason-smt.com
FAQ
1) This is the first time I use this kind of machine, is it easy to operate?
There is English manual or guide video that show you how to use machine.
If you still have any question, please contact us by e-mail / skype/ phone /trademanager online service.
2) If machine have any problem after I receive it, how can I do ?
Free parts send to you in machine warranty period.
If the part is less than 0.5KG, we pay the postage.
If it exceeds 0.5KG, you need to pay the postage.
3) MOQ ?
1 set machine, mixed order is also welcomed.
4) How can I buy this machine from you? ( Very easy and flexible !)
A. Consult us about this product on line or by e-mail.
B. Negotiate and confirm the final price , shipping , payment methods and other terms.
C. Send you the proforma invoice and confirm your order.
D. Make the payment according to the method put on proforma invoice.
E. We prepare for your order in terms of the proforma invoice after confirming your full payment.
And 100% quality check before shipping.
F.Send your order by air or by sea.
5)Why choose us ?
A. Gold supplier on Alibaba !
B. Trade assurance to US$54,000 !
C. Best price & Best shipping & Best service !
