  • FUJI NXT H24 0.5 NOZZLE 2AGKNX005502
FUJI NXT H24 0.5 NOZZLE 2AGKNX005502

FUJI NXT H24 0.5 NOZZLE 2AGKNX005502

  • SMT Nozzle
  • FUJI Nozzle
  • FUJI NXT H24 0.5 NOZZLE 2AGKNX005502
  • Usage:FUJI pick and place machine
  • Product description: FUJI NXT H24 0.5 NOZZLE 2AGKNX005502
  • INQUIRY

FUJI NXT H24 0.5 NOZZLE 2AGKNX005502

Products description


FUJI NXT NOZZLES models as belows:
NOZZLE SIZE H08/H12 H04 H01
0.45*0.3      AA05600
0.7*0.5        AA05700
∅1.0            AA05800 AA06W00 AA0AS00
∅1.3            AA20A00 AA06X00 AA05800
∅1.3 MELF    AA06400 AA0MZ00
∅1.8            AA20B00 AA06Y00 AA06900
∅1.8 MELF    AA19G00 AA11R00
∅2.5            AA20C00 AA06Z00 AA07000
∅2.5 MELF
∅2.5G           AA07F00 AA08400
∅3.7             AA20D00 AA07A00 AA07100
∅3.7G           AA18C00 AA07G00 AA08500
∅5.0             AA20E00 AA07B00 AA07900
∅5.0 G          AA06300 AA07H00 AA07200
∅7.0            AA07C00 AA08000
∅7.0G          AA07K00 AA07300
∅10.0          AA07D00 AA08100
∅10.0G        AA07L00 AA07400
∅15.0          AA07E00 AA08200
∅15.0G        AA07M00 AA07500
∅20.0          AA08300
∅20.0G        AA07600

Fuji nozzle features:
1. CP series nozzles: Original Japan sticker and aluminum,
hard nozzle tube, durable and precision.

2. XP series nozzles: Original manufacture technology, nozzle body adopt
special processing technology with aluminum alloy , nozzle tip and plate
made of ceramic material, do never be white.

3. QP3 series nozzles: The crystal manufacture by original producing technology,
transparency completely conform to the requirements of the original factory.

4. NXT series nozzles: Readable original data two-dimension code,
easily to identification by machine; the nozzle tip made of
ceramic materials, do never be white.

flason smt can supply other Fuji Nozzle models as follows:
FUJI        QP242 Nozzles
Part Number Product Description
ABHPN-6215 Nozzle, 1.0 x R30 x 27
ABHPN-6225 Nozzle, 1.3 x R30 x 27
ABHPN-6235 Nozzle, 1.8 x R30 x 27
ABHPN-6246 Nozzle, 2.5 x R30 x 27
ABHPN-6256 Nozzle, 3.75 x R30 x 27
ABHPN-6276 Nozzle, 7.0 x R30 x 27
ABHPN-6286 Nozzle, 10.0 x R30 x 27
ABHPN-6296 Nozzle, 15.0 x R30 x 27
ABHPN-6306 Nozzle, 20.0 x R30 x 27
ABHPN-6334 Nozzle, 0.7 x R30 x 27
ABHPN-6348 Nozzle, 10.0 x R30 x 18.5, Rubber Tip
ABHPN-6703 Nozzle, 17.5 x R30 x 27, Rubber Tip
ABHPN-6716 Nozzle, 2.5 x R30 x 27, Rubber Tip
ABHPN-6755 Nozzle, 6.5 x R30 x 18.5, Rubber Tip
ABHPN-6765 Nozzle, 7.0 x R30 x 18.5
ABHPN-6775 Nozzle, 10.0 x R30 x 18.5
ABHPN-6785 Nozzle, 15.0 x R30 x 18.5
ABHPN-6795 Nozzle, 20.0 x R30 x 18.5
ABHPN-6805 Nozzle, 15.0 x R30 x 27, Rubber Tip
ABHPN-6814 Nozzle, 7.0 x R30 x 10
ABHPN-6824 Nozzle, 10.0 x R30 x 10
ABHPN-6834 Nozzle, 15.0 x R30 x 10
ABHPN-6844 Nozzle, 20.0 x R30 x 10
ABHPN-6852 Nozzle, 5.0 x R30 x 27, Rubber Tip
ABHPN-6893 Nozzle, 8.0 x R30 x 27, Rubber Tip
ABHPN-8512 Nozzle, 0.7 x S12 x 10
ABHPN-8522 Nozzle, 1.0 x S12 x 10
ABHPN-8532 Nozzle, 1.3 x S12 x 10
ABHPN-8542 Nozzle, 1.8 x S12 x 10
ABHPN-8553 Nozzle, 2.5 x S38 x 10
ABHPN-8563 Nozzle, 2.5 x S38 x 10, Rubber Tip
ABHPN-8573 Nozzle, 3.7 x S38 x 10
ABHPN-8584 Nozzle, 6.5 x S47 x 10, Rubber Tip
ABHPN-8593 Nozzle, 7.0 x S47 x 10
ABHPN-8603 Nozzle, 10.0 x S47 x 10
ABHPN-8613 Nozzle, 2.5 x S38 x 10, Black
ABHPN-8623 Nozzle, 2.5 x S38 x 10, Black, Rubber Tip
ABHPN-8633 Nozzle, 3.7 x S38 x 10, Black
ABHPN-8644 Nozzle, 6.5 x S47 x 10, Black, Rubber Tip
ABHPN-8653 Nozzle, 7.0 x S47 x 10, Black
ABHPN-8663 Nozzle, 10.0 x S47 x 10, Black


1.Short lead time;
2.Quality guaranteed.
3.All size and model available.
Flason SMT are long term and stable supplier of above stated SMT parts.
Flason SMT will Provide high quality and low price goods and perfect follow-up service.

Keywords:

Samsung Nozzle, Yamaha Chip mounter Nozzle, SMT Nozzle, Juki Nozzle, Panasonic Nozzle, Pick and place machine Nozzle, Seimens Nozzle, Yamaha Nozzle, FUJI Nozzle, JUKI Nozzle,Hitachi Nozzle.

Flason Electronic Co.,ltd provide a full SMT assembly line solutions, including SMT Reflow OvenWave Soldering MachinePick and Place MachineSMT Stencil PrinterSMT AOI SPI MachineSMT Reflow OvenSMT Peripheral EquipmentSMT Assembly lineSMT Spare Parts  etc any kind SMT machines you may need, please contact us for more information: wechat whatsapp:+8613691605420, Skype: flasonsmt, Email: sales@flason-smt.com
FAQ
1) This is the first time I use this kind of machine, is it easy to operate?
There is English manual or guide video that show you how to use machine.
If you still have any question, please contact us by e-mail / skype/ phone /trademanager online service.
2) If machine have any problem after I receive it, how can I do ?
Free parts send to you in machine warranty period.
If the part is less than 0.5KG, we pay the postage.
If it exceeds 0.5KG, you need to pay the postage.
3) MOQ ?
1 set machine, mixed order is also welcomed.
4) How can I buy this machine from you? ( Very easy and flexible !)
A. Consult us about this product on line or by e-mail.
B. Negotiate and confirm the final price , shipping , payment methods and other terms.
C. Send you the proforma invoice and confirm your order.
D. Make the payment according to the method put on proforma invoice.
E. We prepare for your order in terms of the proforma invoice after confirming your full payment.
And 100% quality check before shipping.
F.Send your order by air or by sea.
5)Why choose us ?
A. Gold supplier on Alibaba !
B. Trade assurance to US$54,000 !
C. Best price & Best shipping & Best service !
